Journeyman Plumber (UPC/IPC)

A horizontal 2 in fixture branch is installed at the code minimum slope. Over a developed run of 18 ft, how much total fall does the pipe have?

1. A9 in
2. B2-1/4 in
3. C1-1/8 in
4. D4-1/2 inCorrect

Why: Pipe 2-1/2 in and smaller requires a minimum slope of 1/4 in per ft, so 18 ft x 1/4 in = 4-1/2 in of fall. 1-1/8 in comes from using 1/16 in per ft and 2-1/4 in from using the 1/8 in per ft rate that applies only to 3 in and larger pipe. 9 in would be 1/2 in per ft, which is double the required minimum.IPC §704.1

A potable water supply outlet discharges over a receptor and the effective opening of the outlet is 1 in. What is the minimum required air gap?

1. A1-1/2 in
2. B2 inCorrect
3. C3 in
4. D1 in

Why: The air gap must be at least twice the diameter of the effective opening, so 2 x 1 in = 2 in. The 1 in answer is only the code minimum floor that applies to very small openings, not the calculated value here. The 1-1/2 in choice uses a 1.5 multiplier and 3 in uses a 3x multiplier, neither of which the code uses.UPC §603.3.1
